Automatic Titrator
Advantages of Automatic Titrator:
Diversification of titration platforms
Independent analysis station, 16-position 100mL autosampler, 12-position 250mL autosampler, and 18-position 50mL autosampler can be freely selected.
Multiple titration modes
Acid-base titration, redox titration, silver volume titration, complexometric titration, dead-stop titration.
Multiple measurement modes
MEAS: measure pH/mV/T, CAL: pH calibration, SET setting end point mode, MET equivalent titration, MET equivalent titration second-order derivative method (chlorine ion measurement), DET dynamic titration, constant pH titration, manual titration, etc.
Wireless Wi-Fi Module
T9605 wireless Wi-Fi module, wireless connection between computer and the titrator, remote control of the instrument, reducing the time when the experimenter is in close contact with chemical reagents.
Automatic Titrator Specifications:
| Model | UTI-96A | UTI-96PA |
|---|---|---|
| Titration Module | Potentiometric | Potentiometric, Dead-stop |
| mV Measuring Range | -2000.0mV～+2000.0mV | |
| mV Measuring | Resolution: 0.1mV, Accuracy: 0.1mV±0.03% | |
| pH Measuring Range | -20.000pH～+20.000pH | |
| pH Measuring | Resolution: 0.001pH, Accuracy: 0.003pH | |
| Temp. Measuring Range | -5～120℃ | |
| Temp. Accuracy | ±0.1℃ | |
| Maximum Number of Titration Modules | 4 (2 modules in the standard package) | |
| Maximum Number of Simultaneous Filling Modules | 4 (2 modules in the standard package) | |
| Burettes Type | Inbuilt Burette | |
| Burette Optional | 1mL 5mL 10mL 25mL (10ml Burette in the Standard Package ) | |
| Simultaneous Working Burette | 2 | |
| Burette Resolution | 1/1500000 | |
| Burette Refill Time | 16 Seconds (100% Filling Speed) | |
| User Grading Management System | Customizable Operation Permissions | |
| Audit Trail | Optional | Standard |
| Controlled by | PC | |
| Communication Ports | 2*USB, RS232, Internet | |
| WiFi Module | Optional | Standard |
| Stirring | Magnetic Stirring, Mechanical Stirring (Optional) | |
| Electrode Interface Type | mV/pH Measuring Electrode Interface Reference electrode interface | mV/pH Measuring Electrode Interface Reference Electrode Interface |
| PT1000 Temperature Electrode Interface | PT1000 Temperature Electrode Interface Polarized Electrode Interface | |
| Autosampler (Optional) | Equipped with 1 Independent Analysis Station, Optional 16-position 100mL Autosampler, 12-position 250mL Autosampler, and 18-position 50mL Autosampler | |
| Packages Size (WxDxH)(mm) | 415x345x370 | |
| Gross Weight (kg) | 14kg | |
