Automatic Lab Glassware Washer
Laboratory Glassware Washer Specifications:
Model | UWD-160 | UWD-190 | UWD-230 | UWD-230H | UWD-320I | UWD-320H | UWD-680 | |
---|---|---|---|---|---|---|---|---|
Capacity(L) | 158L | 185L | 223L | 223L | 317L | 317L | 680L | |
Display | 8.8inch LCD Touch screen | 7inch LCD Touch screen | ||||||
Standard Program | 30 | 10 | ||||||
Self-defined Program | 120 | 10 | ||||||
Searchable Data Files | Cleaning program files; Cleaning record files; Monitor files | |||||||
Storage | No | SD card(32G) | SD card and USB disk (32G) | |||||
Permission Management System | Three level | Four Level | ||||||
Printer | No | Printer interface | Built in printer | |||||
Drying | Drying System | No | Double spray and heat exchange system with air inlet HEPA filter | |||||
Drying Time Range | No | 0 to 300mins | ||||||
Drying Temp Range | No | RT to 120℃ | ||||||
Drying Method | Chamber Forced Air Drying | Hot air injection via sprinkler (Circulation of hot air is not less than 110 m³/h) | ||||||
Water Inlet pipe | Quantity | 2 | ||||||
Length | Standard: 2m (Customizable) | |||||||
Material | PVC | |||||||
Water Pump | Brand | Sweden | ||||||
Flow Rate | 0-400 L/min | 0-500 L/min | 0-600L/min | 0-800 L/min | 0-800 L/min | 0-1600 L/min | ||
Consumption | 0.37kW | 0.75kW | 0.75kW | 0.75kW | 1.5kW | 1.5kW | ||
Pipeline Pressure Monitoring | No | Yes | ||||||
Structure Material | External | 304 stainless steel | ||||||
Cleaning Chamber | 316 stainless steel | |||||||
Door | Automatic multi-touch intelligent door. In standby mode, there is a gap between the front door and the cavity to facilitate water vapor evaporation. Automatically locks when cleaning starts. | |||||||
Caster | Four universal casters at the bottom of the instrument for easy movement | |||||||
Cleaning Rack | 1 layer | 2 layer | 2 layer | 2 layer | 3 layer | 3 layer | 6 layer | |
Air Heating Consumption | 0.5kW | 3kW | 3kW | 3kW | 4kW | 4kW | 8kW | |
Power Supply | 220/110 50/60Hz | 220/110, 50/60Hz | 380/220V 50/60Hz | 220/110V 50/60Hz | 380/220V, 50/60Hz | |||
Total Consumption | 5kW | 5kW | 5kW | 10kW | 5kW | 10kW | 21kW | |
External Size(W×D×H)(mm) | 640x726 x778 | 670×691 ×940 | 670×760 ×1400 | 670×760 ×140 | 670×757×1650 | 670×757×1650 | 1560×790 ×1980 | |
Shipping Size(W×D×H)(mm) | 970x840 x1350 | 990x860 x1370 | 930x820x1620 | 890x880x1800 | 1680x910 x2100 | |||
N.W./G.W. (kg) | 135/150 | 135/160 | 200/230 | 240/270 | 630/750 |
Advantage of Lab Glassware Washer:
- Advanced microcomputer control system with full color LCD touch screen:
- Graphical and digital display of real-time water inflow, cleaning procedures, cleaning stages, columnar changes in time and temperature, pipeline pressure data and other parameters.
- System software can be redesigned to meet customer needs, and it can support the expansion of hundreds of applications. The desktop can be configured to set up quick launch programs.
- Three optional password protection can be set: Finger Print; Password; No password.
