Biological Safety Cabinet Class II B2, 2FT
Class II B2 BSC Specifications:
Model | UBSC-IIB2-2F | |
---|---|---|
Internal Size (W×D×H)(mm) | 610×550×600 | |
External Size (W×D×H)(mm) | 710x760x2050 | |
Max.Opening | 370mm | |
Work Surface Height | 750mm | |
Control System | Display | 7”LCD touch screen |
Airflow System | Alarm | Abnormal airflow velocity, HEPA filter failure, UV lamp failure, Front window at unsafe height |
Airflow Mode | 100% air exhaust | |
Downflow Velocity | 0.35m/s±0.025m/s | |
Inflow Velocity | 0.52 m/s±0.025m/s | |
Inflow Air Volume | 240m³/h (141CFM) | |
Downflow Air Volume | 560m³/h (330CFM) | |
Exhaust Air Volume | 800m³/h (471CFM) | |
Air filtration System | HEPA Filter | 2pcs H14 HEPA filter, ≥99.995% efficiency at 0.3μm |
Cleanliness Grade | Class 100 (ISO14644.1 Class 5) | |
Cabinet Construction | Main Body | Electro-galvanized steel with antimicrobial Powder Coating |
Work Surface | 304 stainless steel | |
Front Window | Motorized, toughened glass | |
Electrical System | UV Lamp | 15W×1 (Emission of 253.7 nanometers for most efficient decontamination, UV life indicator, UV timer) |
LED Lamp | 10W×2 | |
Max.Consumption | 350W (Not include socket consumption) | |
Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz | |
Illumination | ≥900Lux | |
Sound Emission | ≤65dB(A) | |
Vibration of Work Surface | ≤2μm | |
Standard Accessory | 1. Base Stand 2. LCD Touch Screen; 3. LED Lamp×2; 4. UV Lamp×1; 5. Explosion-Proof/Waterprof Socket×1; 6. Motorized Front Window; 7. Footmaster Caster; 8. Foot Switch; 9. Removable shallow-plate stainless steel work surface; 10. Air Velocity Sensor; 11. Exhaust Blower; 12.6m Exhaust Duct (Φ300mm). | |
Optional Accessory | 1. Gas tap; 2. Water tap; 3. Pressure Sensor; 4. IV Bar With Hooks; 5. ULPA filter; 6. Upgraded LED Lamp; | |
Net Weight | 65kg | |
Gross Weight | 80kg | |
Main Unit | 850×990×1640mm | |
Exhaust Blower | 730×660×500mm | |
Shipping Size (W×D×H)(mm) | 850×990×1640 | |
Shipping Volume | 1.4 m³ |
Class II B2 Biosafety Cabinet Features:
- UV sterilization function and timing function can be set by appointment.
- Motorized front window, control limit and travel limit double protection, ergonomic 10° tilt Angle, improve the operation comfort.
- With memory function in case of power-failure.
- Work area surrounded by negative pressure, prevent leakage,improve Biosafety.
- Audio and visual alarm (Abnormal airflow velocity, HEPA filter failure, UV lamp failure, Front window at unsafe height).
- Interlock function: UV lamp and front window; UV lamp and blower, LED lamp; blower and front window.
- Standard with foot switch: adjust front window to up and down, to avoid airflow turbulence caused by arm movement.
- Optional upgraded LED lamp.
Environment conditions:
Temperature range: 5~40℃
Relative humidity: ≤90%(At +40℃)
Atmospheric pressure: 86kPa-106kPa
Maximum dust concentration: 3500 particles /L(particle size ≥0.5μm)
Optional upgrade LED lamp can be choosed.
Color Rendering Index up to Ra98, Truly restore the true color of the experimental object, the experimental results are more accurate.
RG0 without blue light, protects the operator from blue light.
